1.89 Inch AMOLED Display Module 1600*1200 Resolution With Medical Grade Certification
Product Description
1.89-inch Industrial and Medical Screen - 1600*1200 High-definition OLED with 1000cd/m² High Brightness, Suitable for Medical Equipment/Industrial Control, Wide Temperature Range and Anti-interference
Micro OLED Product Knowledge
The key advantages of Micro OLED (Silicon-based OLED) is an advanced display technology:
- Ultra-High Pixel Density (PPI)
- Thin, Lightweight, and compact
- Superior Image Quality
- Lower power consumption
- Wide operating Temperature Range
- High brightness & Efficiency (with advanced designs)
- Manufacturing & Scalability benefits
Micro OLED Disadvantages:
- High production costs & limited supply
- Limited brightness (compared to Micro LED)
- Limited view angles
- Shorter lifespan (compared to micro LED)
- Limited application scope (small display only)
- Motion Blur & Persistence issues (in VR)
- Competition from micro LED
Huaxin Advantage
- Factory base located at inland city which has cost effective
- Most advanced new equipment which can keep quality stable
- Most processes using fully automatic equipment which has efficiency and stable quality
- Professional engineers and production leaders who works in LCD field for more than 20 years
- Self design for customized product
Our certificates:
- ISO14001
- ISO9001/IATF16949
- SGS of LCD module
Huaxin Technology (Enshi) Co., LTD
- Hubei.Enshi
- Date of foundation: 2009
- High technology enterprise mainly work on research and development, producing and sells LCD, LCM, TFT, backlight, OLED
- LCD includes: VA, TN, HTN, STN, FSTN, CSTN and other series
- LCM includes: COB, TBA, COG, TP, OLED and other series
- Register capital: twenty million
- Current staff: 500+
- R&D accounts for 10%
- QC accounts for 15%
Micro OLED vs. Traditional OLED vs. Micro LED
| Feature | Micro OLED | Traditional OLED | MicroLED |
| Substrate | Silicon wafer | Glass/plastic | Sapphire/glass |
| PPI | 3,000-5,000+ | 400-800 | 1,000+ |
| Size | <1 inch common | Smartphone/TV sizes | Scalable |
| Power Use | Low | Medium | Very Low |
| Lifespan | Moderate (OLED aging) | Moderate | Very Long |
| Cost | High | Moderate | Very high |
Challenges:
- Limited lifespan (blue OLEDs degrade faster)
- Higher manufacturing cost due to silicon wafer integration
- Currently small sizes (not suitable for TVs)
Future of Micro OLED:
Expected to dominate AR/VR and wearable displays due to unmatched pixel density.
Companies like Sony, Samsung, BOE, and eMagin are investing heavily in this tech.
